Versuchsaufbau
- Ziel ist es das die PBX asterisk den Pseudo Provider stellt
- Über ihn sollen alle nicht lokalen Gespräche laufen.
- Er hat die Vorwahl 00
- Die anderen die Vorwahl 01 bis 12
asterix
- cat sip.conf
;asterix sip.conf [general] [idefix] type=friend context=default ;type=peer insecure=port,invite host=dynamic disallow=all allow=ulaw allow=gsm secret=mysupersecret qualify=yes [0001] type=friend context=default disallow=all allow=ulaw allow=gsm host=dynamic secret=pass1
- cat extentions.conf
;asterix extention.conf [default] exten => _00XX,1,Dial(SIP/${EXTEN},30,r) exten => _01XX,1,Dial(SIP/${EXTEN}@idefix)
idefix
- cat sip.conf
;idefix sip.conf [general] register => idefix:mysupersecret@asterix.lab.intra/asterix [asterix] ;type=friend type=peer insecure=port,invite context=default host=asterix.lab.intra disallow=all allow=ulaw allow=gsm secret=mysupersecret [0101] type=friend context=default disallow=all allow=ulaw allow=gsm host=dynamic secret=pass1
- cat extensions.conf
;idefix extention.conf [default] exten => _01XX,1,Dial(SIP/${EXTEN},30,r) exten => _0XXX,1,Dial(SIP/${EXTEN}@asterix,30,r)
